UV Fused Silica Optical Beam Splitters 20Hz Plate Beam Splitter

  • UV Fused Silica Optical Beam Splitters 20Hz Plate Beam Splitter
Place of Origin Wuhan, China
Brand Name STAR OPTIC
Certification RoHS, ISO9001
Model Number BSP
Minimum Order Quantity 5pcs
Price Negotiable
Packaging Details Safe and dust-free packing
Delivery Time Negotiable
Payment Terms T/T, Western Union, Paypal
Supply Ability 50000pcs/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Plate Beamsplitter Material Thin Flat Optical Glass
T/R 10/90, 20/80, 30/70, 40/60, 50/50 Etc. Surface Front Surface Partially Reflective Coating, Back Surface AR Coated
AOI 45° Cosmetic 60/40 Scratch And Dig
High Light

Optical Beam Splitters 20Hz

,

20Hz Plate Beam Splitter

,

UV Fused Silica Optical Beam Splitters
Leave a Message
Product Description

Plate Beamsplitter, Wide Variety Of Splitting Ratios Over 400-1200nm

Overview:
Plate Beamsplitters consist of a thin, flat glass plate that has been coated on the first surface to split incident light by a specified ratio that is independent of the light's wavelength or polarization state, while the back surface AR coated in order to improve efficiency and minimize ghosting and interference effects.Plate beamsplitters are often designed for a 45° AOI.


General Specifications of Plate Beamsplitter:

Material BK7, UV Fused Silica
Dimension Tolerance +0/-0.2mm
Thickeness Tolerance ±0.2mm
Clear Aperture >90%
Flatness λ/4@632.8nm
Parallelism <1 arc minutes
Surface Quality 60/40 Scratch and Dig
Coating

Partial reflecting Coating on front surface
AR coating on back surface
T/R ±5%, T=(Ts+Tp)/2, R=(Rs+Rp)/2
Damage Threshold >1J/cm2, 20ns, 20Hz, @1064nm



UV Fused Silica Optical Beam Splitters 20Hz Plate Beam Splitter 0


Standard Products of Cube Beamsplitter:

Part No. Material Dimension
(mm)		 Thickness
(mm)		 T/R
(%)		 Wavelength
(nm)		 Polarization AOI
(°)
BSP12-T20-400-700 N-BK7 12.7 3 20/80 400-700 Avg. 45
BSP25-T20-400-700 N-BK7 25.4 3 20/80 400-700 Avg. 45
BSP50-T20-400-700 N-BK7 50.8 3 20/80 400-700 Avg. 45
BSP12-T30-400-700 N-BK7 12.7 3 30/70 400-700 Avg. 45
BSP25-T30-400-700 N-BK7 25.4 3 30/70 400-700 Avg. 45
BSP50-T30-400-700 N-BK7 50.8 3 30/70 400-700 Avg. 45
BSP12-T40-400-700 N-BK7 12.7 3 40/60 400-700 Avg. 45
BSP25-T40-400-700 N-BK7 25.4 3 40/60 400-700 Avg. 45
BSP50-T40-400-700 N-BK7 50.8 3 40/60 400-700 Avg. 45
BSP12-T50-400-700 N-BK7 12.7 3 50/50 400-700 Avg. 45
BSP25-T50-400-700 N-BK7 25.4 3 50/50 400-700 Avg. 45
BSP50-T50-400-700 N-BK7 50.8 3 50/50 400-700 Avg. 45
BSP1212-T50-400-700 N-BK7 12.7x12.7 3 50/50 400-700 Avg. 45
BSP2525-T50-400-700 N-BK7 25.4x25.4 3 50/50 400-700 Avg. 45
BSP5050-T50-400-700 N-BK7 50.8x50.8 3 50/50 400-700 Avg. 45
BSP12-T60-400-700 N-BK7 12.7 3 60/40 400-700 Avg. 45
BSP25-T60-400-700 N-BK7 25.4 3 60/40 400-700 Avg. 45
BSP50-T60-400-700 N-BK7 50.8 3 60/40 400-700 Avg. 45
BSP12-T70-400-700 N-BK7 12.7 3 70/30 400-700 Avg. 45
BSP25-T70-400-700 N-BK7 25.4 3 70/30 400-700 Avg. 45
BSP50-T70-400-700 N-BK7 50.8 3 70/30 400-700 Avg. 45
BSP12-T80-400-700 N-BK7 12.7 3 80/20 400-700 Avg. 45
BSP25-T80-400-700 N-BK7 25.4 3 80/20 400-700 Avg. 45
BSP50-T80-400-700 N-BK7 50.8 3 80/20 400-700 Avg. 45
BSP12-T20-650-900 N-BK7 12.7 3 20/80 650-900 Avg. 45
BSP25-T20-650-900 N-BK7 25.4 3 20/80 650-900 Avg. 45
BSP50-T20-650-900 N-BK7 50.8 3 20/80 650-900 Avg. 45
BSP12-T30-650-900 N-BK7 12.7 3 30/70 650-900 Avg. 45
BSP25-T30-650-900 N-BK7 25.4 3 30/70 650-900 Avg. 45
BSP50-T30-650-900 N-BK7 50.8 3 30/70 650-900 Avg. 45
BSP12-T40-650-900 N-BK7 12.7 3 40/60 650-900 Avg. 45
BSP25-T40-650-900 N-BK7 25.4 3 40/60 650-900 Avg. 45
BSP50-T40-650-900 N-BK7 50.8 3 40/60 650-900 Avg. 45
BSP12-T50-650-900 N-BK7 12.7 3 50/50 650-900 Avg. 45
BSP25-T50-650-900 N-BK7 25.4 3 50/50 650-900 Avg. 45
BSP50-T50-650-900 N-BK7 50.8 3 50/50 650-900 Avg. 45
BSP1212-T50-650-900 N-BK7 12.7x12.7 3 50/50 650-900 Avg. 45
BSP2525-T50-650-900 N-BK7 25.4x25.4 3 50/50 650-900 Avg. 45
BSP5050-T50-650-900 N-BK7 50.8x50.8 3 50/50 650-900 Avg. 45
BSP12-T60-650-900 N-BK7 12.7 3 60/40 650-900 Avg. 45
BSP25-T60-650-900 N-BK7 25.4 3 60/40 650-900 Avg. 45
BSP50-T60-650-900 N-BK7 50.8 3 60/40 650-900 Avg. 45
BSP12-T70-650-900 N-BK7 12.7 3 70/30 650-900 Avg. 45
BSP25-T70-650-900 N-BK7 25.4 3 70/30 650-900 Avg. 45
BSP50-T70-650-900 N-BK7 50.8 3 70/30 650-900 Avg. 45
BSP12-T80-650-900 N-BK7 12.7 3 80/20 650-900 Avg. 45
BSP25-T80-650-900 N-BK7 25.4 3 80/20 650-900 Avg. 45
BSP50-T80-650-900 N-BK7 50.8 3 80/20 650-900 Avg. 45
BSP12-T20-900-1200 N-BK7 12.7 3 20/80 900-1200 Avg. 45
BSP25-T20-900-1200 N-BK7 25.4 3 20/80 900-1200 Avg. 45
BSP50-T20-900-1200 N-BK7 50.8 3 20/80 900-1200 Avg. 45
BSP12-T30-900-1200 N-BK7 12.7 3 30/70 900-1200 Avg. 45
BSP25-T30-900-1200 N-BK7 25.4 3 30/70 900-1200 Avg. 45
BSP50-T30-900-1200 N-BK7 50.8 3 30/70 900-1200 Avg. 45
BSP12-T40-900-1200 N-BK7 12.7 3 40/60 900-1200 Avg. 45
BSP25-T40-900-1200 N-BK7 25.4 3 40/60 900-1200 Avg. 45
BSP50-T40-900-1200 N-BK7 50.8 3 40/60 900-1200 Avg. 45
BSP12-T50-900-1200 N-BK7 12.7 3 50/50 900-1200 Avg. 45
BSP25-T50-900-1200 N-BK7 25.4 3 50/50 900-1200 Avg. 45
BSP50-T50-900-1200 N-BK7 50.8 3 50/50 900-1200 Avg. 45
BSP1212-T50-900-1200 N-BK7 12.7x12.7 3 50/50 900-1200 Avg. 45
BSP2525-T50-900-1200 N-BK7 25.4x25.4 3 50/50 900-1200 Avg. 45
BSP5050-T50-900-1200 N-BK7 50.8x50.8 3 50/50 900-1200 Avg. 45
BSP12-T60-900-1200 N-BK7 12.7 3 60/40 900-1200 Avg. 45
BSP25-T60-900-1200 N-BK7 25.4 3 60/40 900-1200 Avg. 45
BSP50-T60-900-1200 N-BK7 50.8 3 60/40 900-1200 Avg. 45
BSP12-T70-900-1200 N-BK7 12.7 3 70/30 900-1200 Avg. 45
BSP25-T70-900-1200 N-BK7 25.4 3 70/30 900-1200 Avg. 45
BSP50-T70-900-1200 N-BK7 50.8 3 70/30 900-1200 Avg. 45
BSP12-T80-900-1200 N-BK7 12.7 3 80/20 900-1200 Avg. 45
BSP25-T80-900-1200 N-BK7 25.4 3 80/20 900-1200 Avg. 45
BSP50-T80-900-1200 N-BK7 50.8 3 80/20 900-1200 Avg. 45
