Clear Aperture 90% Achromatic Optical Lenses for Optimal Light Control in Industrial Applications

Product Description:

The Optical Cylinder Lens is a cutting-edge optical component designed for precise light manipulation and control. With a design wavelength of 632.8nm, this cylindrical glass lens is optimized for applications requiring high accuracy and performance in the visible spectrum.

Equipped with an anti-reflective coating, this aspherical optical lens minimizes unwanted reflections and enhances light transmission efficiency. The coating ensures that the lens delivers exceptional clarity and sharpness, making it ideal for demanding optical systems that require superior image quality.

Constructed from high-quality optical glass, the substrate of this cylindrical lens offers excellent optical properties and durability. The optical glass material provides the lens with exceptional thermal stability and resistance to environmental factors, ensuring consistent performance over time.

One of the standout features of this optical cylinder lens is its capability for one-dimensional beam shaping. By effectively manipulating the light passing through the lens, it enables precise control over the shape and direction of the output beam. This feature is particularly advantageous in applications that require tailored light distribution patterns and focused illumination.

Furthermore, the lens is meticulously polished to meet stringent optical specifications. With a surface quality of N<3(0.5)@632.8nm, the lens exhibits minimal surface imperfections and ensures high optical throughput. The precise polishing process contributes to the overall performance of the lens, allowing it to deliver sharp and distortion-free images.

In addition to its primary attributes, the Optical Cylinder Lens offers versatility in various optical applications. Whether used in laser systems, imaging devices, or scientific instruments, this lens excels in providing accurate light manipulation and beam control.

For applications requiring precise light focusing and shaping, the Optical Cylinder Lens stands out as a reliable and high-performance optical component. Its design wavelength of 632.8nm, anti-reflective coating, optical glass substrate, one-dimensional beam shaping feature, and exceptional polishing make it a preferred choice for professionals in fields such as laser technology, microscopy, and optical instrumentation.

Experience the innovation and precision of the Optical Cylinder Lens for your optical system needs. Elevate your optical setup with this advanced aspherical lens designed to deliver outstanding performance and reliability in demanding applications.

Features:

• Product Name: Optical Cylinder Lens
• Size: 25.4mm
• Design Wavelength: 632.8nm
• Optical Thin Film: AR Coatings For UV, VIS To IR
• Coating Wavelength Range: 400-700nm
• Coating: Anti-reflective

Technical Parameters:

Applications:

STAR OPTIC's CYX Optical Cylinder Lens is a versatile product that can be applied in various occasions and scenarios due to its exceptional attributes and specifications.

These cylindrical glass lenses are ideal for use in a wide range of optical applications, including but not limited to:

• Machine Vision Systems: The CYX lens can be used in machine vision systems for industrial inspection, quality control, and automated manufacturing processes.
• Laser Systems: With a design wavelength of 632.8nm, these lenses are perfect for use in laser systems for cutting, drilling, marking, and other laser processing applications.
• Medical Devices: The high-quality achromatic and aspherical optical lenses of the CYX model make it suitable for medical devices such as endoscopes, microscopes, and laser surgery equipment.
• Scientific Instruments: These lenses are well-suited for scientific instruments used in research labs, universities, and observatories for a wide range of applications.

Manufactured in Wuhan, China, these lenses meet the highest quality standards, holding RoHS and ISO9001 certifications. The minimum order quantity is only 5pcs, making it accessible for both small-scale projects and large-scale productions.

STAR OPTIC offers negotiable pricing, flexible delivery times, and various payment terms including T/T, Western Union, and Paypal. The lenses are carefully packaged in safe and dust-free packing to ensure their protection during transit.

With a supply ability of 50000pcs per month, customers can rely on a consistent and reliable source of these optical lenses. The lenses are designed to work across a broad wavelength range from UV to IR, making them highly versatile for different applications.

The CYX Optical Cylinder Lens comes in dimensions ranging from 10x20 to 20x20 and can also be customized to meet specific requirements. The substrate used is optical glass, ensuring excellent optical performance and durability.

Whether you are in need of achromatic optical lenses, aspherical optical lenses, or cylindrical glass lenses, the CYX model from STAR OPTIC is a top choice for professionals in various industries.
