550-750nm Achromatic Quarter Wave Plate 13.5mm Low Temperature Sensitivity

  • 550-750nm Achromatic Quarter Wave Plate 13.5mm Low Temperature Sensitivity
Place of Origin Wuhan, China
Brand Name STAR OPTIC
Certification RoHS, ISO9001
Model Number WPA
Minimum Order Quantity 1pc
Price Negotiable
Packaging Details Safe and dust-free packing
Delivery Time Negotiable
Payment Terms T/T, Western Union, Paypal
Supply Ability 50000pcs/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Achromatic λ/4 Quarter Wave Plate Material Crystal Quartz+MgF2
Retardance λ/4 Applications Tunable Laser Sources, Multiple Laser Line Systems
Feature Wide Spectral Bandwidth Type Cemented & Air Spaced
High Light

750nm Achromatic Quarter Wave Plate

,

Quarter Wave Plate 750nm

,

Achromatic Quarter Wave Plate 13.5mm
Leave a Message
Product Description

Achromatic Λ/4 Quarter Wave Plate, Wide Spectral Bandwidth For Tunable Lasers

Overview:

Achromatic Wave Plates (Retarders) are a pair of crystalline quartz and magnesium fluoride plates of controlled thickness with crossed fast axes to create a λ/2 or λ/4 delay in the broad wavelength range. Quarter wave plates can turn linearly polarized light into circularly polarized light and vice versa. The difference in dispersion between materials allows the arrangement of a slow phase shift over a broad wavelength range.

Achromatic waveplates are needed for various devices, such as tunable laser sources, multiple laser line systems, and other broad-spectrum sources. Achromatic (Broadband) waveplates could be used to replace a number of single-wavelength quartz waveplates, making your system more convenient and easier to use.



Star optic offers Achromatic Waveplates (Retarders) in air spaced and cemented feature. And air spaced waveplates are mounted in a black anodized aluminium housing with the fast axis clearly indicated. For cemented waveplates, you can choose mount or not according to your needs.







Main Features of Achromatic Wave Plate:

  • Wide spectral bandwidth
  • Low temperature sensitivity
  • Large sizes available







General Specifications Of Achromatic λ/4 Quarter Wave Plate:

Material Crystal Quartz+MgF2
Dimension Tolerance +0.0/-0.2mm
Surface Quality 40/20 scratch and dig
Clear Aperture >90% central area
Wavefront Distortion <λ/4@632.8nm (for air spaced type)
Parallelism <10 arc seconds (for single plate)
Retardation Tolerance <λ/100
Standard Wave

quarter-wave(λ/4)
Standard Wavelength 450-650nm
550-750nm
650-1100nm
900-2100nm
Coating Both sides AR coated, R<1% per face
Damage Threshold Cemented: >500mJ/cm2, 20ns, 20Hz @1064nm
Air spaced: >5J/cm2, 20ns, 20Hz @1064nm







Standard Products Of  Achromatic λ/4 Quarter Wave Plate:

Part Number Type Diameter (mm) Retardation (λ) Wavelength (nm) Mount (mm) Clear Aperture (mm)
WPAC410-450-650 Cemented 10 λ/4 450-650 / 8
WPAC415-450-650 Cemented 15 λ/4 450-650 / 13.5
WPAC410-550-750 Cemented 10 λ/4 550-750 / 8
WPAC415-550-750 Cemented 15 λ/4 550-750 / 13.5
WPAC410-650-1100 Cemented 10 λ/4 650-1100 / 8
WPAC415-650-1100 Cemented 15 λ/4 650-1100 / 13.5
WPAC410-900-2100 Cemented 10 λ/4 900-2100 / 8
WPAC415-900-2100 Cemented 15 λ/4 900-2100 / 13.5
WPAI420-450-650 Air Spaced 20 λ/4 450-650 φ25.4x6 18
WPAI420-550-750 Air Spaced 20 λ/4 550-750 φ25.4x6 18
WPAI420-650-1100 Air Spaced 20 λ/4 650-1100 φ25.4x6 18
WPAI420-900-2100 Air Spaced 20 λ/4 900-2100 φ25.4x6 18
